YASKAWA V1000 Technical Manual

n
Drive Software Version PRG: 1018 and Later
Table B.22 400 V, 1150 rpm Type Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1432 1433 1435 1436 1438 143A 143B 143D 143E 143F
Voltage Class − 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac
Rated Power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW 5.5 kW 7.5 kW 11 kW 15 kW 18 kW
Rated Speed r/min 1150 1150 1150 1150 1150 1150 1150 1150 1150 1150
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5
E5-03 Motor Rated Current A 0.94 1.51 3.00 4.43 7.08 10.1 13.33 19.9 27.8 31.8
E5-04 Motor Pole Number – 6 6 6 6 6 6 6 6 6 6
E5-05
Motor Winding
Resistance
Ω 19.32 10.8 4.456 2.044 1.483 1.215 0.66 0.443 0.331 0.264
E5-06 d-Axis Inductance mH 194.7 129.2 76.88 48.6 37.58 44.54 26.36 19.1 15.09 13.32
E5-07 q-Axis Inductance mH 252.84 160.9 97.52 61.4 47.65 56.26 34.2 24.67 18.56 18
E5-09
Induction Voltage
Constant 1
mVs/rad 640.9 654.1 728.8 688.9 702.0 861.5 783.0 762.2 749.6 842.7
E5-24
Induction Voltage
Constant 2
mV/(r/
min)
0 0 0 0 0 0 0 0 0 0
E1-04
Maximum Output
Frequency
Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-05
Maximum Output
Voltage
V 380 380 380 380 380 380 380 380 380 380
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-09
Minimum Output
Frequency
Hz 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9
L3-24
<1>
Motor Acceleration
Time for Inertia
Calculations
s 0.062 0.044 0.08 0.09 0.067 0.072 0.088 0.073 0.062 0.091
n8-49
d-Axis Current for
High-Efficiency
Control
% –8.8 –9.9 –9.3 –10 –12.8 –12.3 –15.3 –16.7 –14.9 –17.9
<1> Default setting value is dependent on parameter o2-04, Drive Model Selection.
B.7 Parameters that Change with the Motor Code Selection
402
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
