YASKAWA V1000 Technical Manual

Register No. Contents
00ACH
Motor Speed (Open Loop
Vector only)
r/min units
<4>
00ADH 0.01% units
00AEH, 00AFH Reserved
00B0H Option Code
The following lists the 3 and 4 letter ASCII codes stored for each serial communication option:
CANopen (Model: SI-S3/V): 5353H
CC-Link (Model: SI-C3/V): 5343H
DeviceNet (Model: SI-N3/V): 534EH
PROFIBUS-DP (Model: SI-P3/V): 5350H
MECHATROLINK-II (Model: SI-T3/V): 5354H
MECHATROLINK-III (Model: SI-ET3/V): 1004H
CompoNet (Model: SI-M3/V): 434EH
Other options use their own unique codes. Refer
to the communication option instruction manual
for the option code.
00B1H to 00B4H Reserved
00B5H
Frequency Reference After
Soft-starter
r/min units
<4>
00B6H 0.01% units
00B7H
Frequency Reference
r/min
<4>
00B8H 0.01% units
00BFH oPE Error Number
00C0H
Fault contents 3
bit 0 Reserved
bit 1 Undervoltage (Uv1)
bit 2 Control Power Supply Undervoltage (Uv2)
bit 3 Soft Charge Circuit Fault (Uv3)
bit 4 IGBT Short Circuit or Ground Fault (SC)
bit 5 Ground Fault (GF)
bit 6 Overcurrent (oC)
bit 7 Overvoltage (ov)
bit 8 Heatsink Overheat (oH)
bit 9 Heatsink Overheat (oH1)
bit A Motor Overload (oL1)
bit B Drive Overload (oL2)
bit C Overtorque Detection 1 (oL3)
bit D Overtorque Detection 2 (oL4)
bit E Dynamic Braking Transistor Fault (rr)
bit F Braking Resistor Overheat (rH)
00C1H
Fault contents 4
bit 0 External Fault at input terminal S3 (EF3)
bit 1 External Fault at input terminal S4 (EF4)
bit 2 External Fault at input terminal S5 (EF5)
bit 3 External Fault at input terminal S6 (EF6)
bit 4 External Fault at input terminal S7 (EF7)
bit 5 to 6 Reserved
bit 7 Overspeed (oS)
bit 8 Excessive Speed Deviation (dEv)
bit 9 PG Disconnected (PGo)
bit A Input Phase Loss (PF)
bit B Output Phase Loss (LF)
bit C Motor Overheat Alarm (PTC input) (oH3)
bit D Digital Operator Connection Fault (oPr)
bit E EEPROM Write Error (Err)
bit F Motor Overheat Fault (PTC input) (oH4)
C.10 MEMOBUS/Modbus Data Table
422
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
