YASKAWA V1000 Technical Manual

No. Name
User
Setting
L8-01
Internal Dynamic Braking Resistor
Protection Selection (ERF type)
L8-02 Overheat Alarm Level
L8-03 Overheat Pre-Alarm Operation Selection
L8-05 Input Phase Loss Protection Selection
L8-07 Output Phase Loss Protection Selection
L8-09 Output Ground Fault Detection Selection
L8-10 Heatsink Cooling Fan Operation Selection
L8-11 Heatsink Cooling Fan Operation Delay Time
L8-12 Ambient Temperature Setting
L8-15 oL2 Characteristics Selection at Low Speeds
L8-18 Soft Current Limit Selection
L8-19
Frequency Reduction Rate during oH
Pre-Alarm
L8-29 Current Unbalance Detection (LF2)
L8-35 Side-by-Side Selection
L8-38 Carrier Frequency Reduction
L8-41 Current Alarm Selection
L8-51 STo Fault Detection Level
L8-54 STo Deviation Detection
n1-01 Hunting Prevention Selection
n1-02 Hunting Prevention Gain Setting
n1-03 Hunting Prevention Time Constant
n1-05 Hunting Prevention Gain while in Reverse
n2-01
Speed Feedback Detection Control (AFR)
Gain
n2-02
Speed Feedback Detection Control (AFR)
Time Constant
n2-03
Speed Feedback Detection Control (AFR)
Time Constant 2
n3-01
High-Slip Braking Deceleration Frequency
Width
n3-02 High-Slip Braking Current Limit
n3-03 High-Slip Braking Dwell Time at Stop
n3-04 High-Slip Braking Overload Time
n3-13 Overexcitation Deceleration Gain
n3-21 High-Slip Suppression Current Level
n3-23 Overexcitation Operation Selection
n6-01
Line-to-Line Motor Resistance Online
Tuning
n8-45 Speed Feedback Detection Control Gain
n8-47 Pull-In Current Compensation Time Constant
n8-48 Pull-In Current
n8-49 Load Current
n8-51 Acceleration Time Pull-In Current
n8-54 Voltage Error Compensation Time Constant
n8-55 Load Inertia
n8-62 Output Voltage Limit
n8-63 Output Voltage Limit Gain 1
n8-65
Speed Feedback Detection Control Gain
during ov Suppression
n8-68 Output Voltage Limit Gain 2
n8-87 Output Voltage Limit Selection
n8-88
Output Voltage Limit Switching Current
Level
n8-89
Output Voltage Limit Switching Current
Hysteresis Width
No. Name
User
Setting
n8-90 Output Voltage Limit Switching Speed
n8-91 Id Limit for Output Voltage Limit Control
o1-01 Drive Mode Unit Monitor Selection
o1-02 User Monitor Selection After Power Up
o1-03 Digital Operator Display Selection
o1-05 LCD Contrast Control
o1-10
Frequency Reference Setting and User-Set
Display
o1-11
Frequency Reference Setting/Decimal
Display
o2-01 LOCAL/REMOTE Key Function Selection
o2-02 STOP Key Function Selection
o2-03 User Parameter Default Value
o2-04 Drive/kVA Selection
o2-05
Frequency Reference Setting Method
Selection
o2-06
Operation Selection when Digital Operator is
Disconnected
o2-07
Motor Direction at Power Up when Using
Operator
o4-01 Accumulated Operation Time Setting
o4-02 Accumulated Operation Time Selection
o4-03
Cooling Fan Maintenance Setting (Operation
Time)
o4-05 Capacitor Maintenance Setting
o4-07
DC Bus Pre-Charge Relay Maintenance
Setting
o4-09 IGBT Maintenance Setting
o4-11 U2, U3 Initialization
o4-12 kWh Monitor Initial Value Selection
o4-13 Motor r/min Reset
r1-01 DWEZ Connection Parameter 1 (upr.)
r1-02 DWEZ Connection Parameter 1 (lwr.)
r1-03 DWEZ Connection Parameter 2 (upr.)
r1-04 DWEZ Connection Parameter 2 (lwr.)
r1-05 DWEZ Connection Parameter 3 (upr.)
r1-06 DWEZ Connection Parameter 3 (lwr.)
r1-07 DWEZ Connection Parameter 4 (upr.)
r1-08 DWEZ Connection Parameter 4 (lwr.)
r1-09 DWEZ Connection Parameter 5 (upr.)
r1-10 DWEZ Connection Parameter 5 (lwr.)
r1-11 DWEZ Connection Parameter 6 (upr.)
r1-12 DWEZ Connection Parameter 6 (lwr.)
r1-13 DWEZ Connection Parameter 7 (upr.)
r1-14 DWEZ Connection Parameter 7 (lwr.)
r1-15 DWEZ Connection Parameter 8 (upr.)
r1-16 DWEZ Connection Parameter 8 (lwr.)
r1-17 DWEZ Connection Parameter 9 (upr.)
r1-18 DWEZ Connection Parameter 9 (lwr.)
r1-19 DWEZ Connection Parameter 10 (upr.)
r1-20 DWEZ Connection Parameter 10 (lwr.)
r1-21 DWEZ Connection Parameter 11 (upr.)
r1-22 DWEZ Connection Parameter 11 (lwr.)
r1-23 DWEZ Connection Parameter 12 (upr.)
r1-24 DWEZ Connection Parameter 12 (lwr.)
r1-25 DWEZ Connection Parameter 13 (upr.)
E.3 User Setting Table
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
461
E
Quick Reference Sheet

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
