YOKOGAWA ADMAG TI Series

<5. Functions>
150
IM 01E21A02-03EN
Device Information Duplicate Data Restore Data Compulsion Data
Sensor Serial No -

-
Main Board Software Rev.
 
-
Sensor Board Software Rev.
 
-
Display Board Software Rev.
 
-
Model(Note)
 
-
Communication and I/O Code
 
-
NOTE
Data can only be duplicated or restored between products of the same model code.
Thesettingcanbeconguredwiththefollowingparameters.
For details about the restorable parameters, refer to Subsection 5.11.3.
Menu path
Display Devicesetup►Diag/Service►Parambkup/restore►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►MTB►DeviceConguration►Maintenance►Parameter
Backup/Restore►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
MTB 83 Restore execute Restore Execute
Speciestheexecutionofthe
restore function.
*1
MTB 84 Restore result Restore Result
Displays the result of the
restore function.
*2
*1: From the table below, select the execution of the restore function. In the communication access of F
OUNDATION
Fieldbus, the communication access is set with the procedures of the interactive operation guide called DD Method.
Selection
Description
Display F
OUNDATION Fieldbus
Not execute Not execute Does not restore data.
Duplicate data 1 Duplicate Data1
Restorestheparameter(DuplicateData)settingfrommemory1
on the display board to the main board of the product.
Duplicate data 2 Duplicate Data2
Restorestheparameter(DuplicateData)settingfrommemory2
on the display board to the main board of the product.
Duplicate data 3 Duplicate Data3
Restorestheparameter(DuplicateData)settingfrommemory3
on the display board to the main board of the product.
Duplicate SD Duplicate SD
Restorestheparameter(DuplicateData)settingfromthe
microSD card to the main board of the product.
Restore data 1 Restore Data1
Restorestheparameter(RestoreData)settingfrommemory1
on the display board to the main board of the product.
Restore data 2 Restore Data2
Restorestheparameter(RestoreData)settingfrommemory2
on the display board to the main board of the product.
Restore data 3 Restore Data3
Restorestheparameter(RestoreData)settingfrommemory3
on the display board to the main board of the product.
Restore SD Restore SD
Restorestheparameter(RestoreData)settingfromthemicroSD
card to the main board of the product.
Compulsion data 1 Compulsion Data1
Restorestheparameter(CompulsionData)settingfrommemory
1 on the display board to the main board of the product.
Compulsion data 2 Compulsion Data2
Restorestheparameter(CompulsionData)settingfrommemory
2 on the display board to the main board of the product.
Compulsion data 3 Compulsion Data3
Restorestheparameter(CompulsionData)settingfrommemory
3 on the display board to the main board of the product.
Compulsion SD Compulsion SD
Restorestheparameter(CompulsionData)settingfromthe
microSD card to the main board of the product.
Restore factory Restore Factory
Restores to the status that is set at shipment from the
manufacturing factory.
