<5. Functions>
151
IM 01E21A02-03EN
*2: The result of the restore function is displayed as shown below.
Selection
Description
Display
F
OUNDATION
Fieldbus
Unexecuted Unexecuted Does not restore data.
Success Success Succeeded in restoration.
Failure Failure Failed in restoration.
Running Running Restore running
The table below shows alarms whose parameters can be restored or duplicated when an alarm
occurs.
: Executable when an alarm occurs.
-: Not executable when alarm occurs.
Alarm Name
Restore or
Duplicate
Display F
OUNDATION Fieldbus
010:Main CPU FAIL 10:Main board CPU failure -
011:Rev calc FAIL 11:Reverse calculation failure -
012:Main EEP FAIL 12:Main board EEPROM failure -
013:MainEEPdt 13:Main board EEPROM default -
014:Snsr bd FAIL 14:Sensor board failure

015:Snsr comm ERR 15:Sensor communication error

016:AD1FAIL[Sig] 16:A/D1failure[Signal]

017:AD2FAIL[Excit] 17:A/D2failure[Exciter]

018:Coil open 18:Coil open

019:Coil short 19:Coil short

020:Exciter FAIL 20:Exciter failure

027:Restore FAIL 27:Parameter restore incomplete

028:Ind bd FAIL 28:Indicator board failure -
029:Ind bd EEP FAIL 29:Indicator board EEP failure -
030:LCD drv FAIL 30:LCD driver failure -
031:Ind bd mismatch 31:Indicator board mismatch -
032:Ind comm ERR 32:Indicator communication error -
033:microSD FAIL 33:microSD failure -
050:Signaloverow 50:Signaloverow

051:Empty detect 51:Empty pipe detection

053:Adh over lv 4 53:Adhension over level 4

060:Span cfg ERR 60:Spancongurationerror -
066:Density cfg ERR 66:Densitycongurationerror -
067:Pls 1 cfg ERR 67:Pulse output 1 cfg error -
069:Nomi size cfg 69:Nominal size cfg error -
070:Adh cfg ERR 70:Adhesioncongurationerror -
071:FLN cfg ERR 71:Flow noise cfg error -
072:Log not start 72:Data logging not started -
082:Pls 1 saturate 82:Pulse output 1 saturated

085:Cable miscon 85:Cable misconnect

086:Coil insulation 86:Coil insulation warning

087:Adhesion lv 3 87:Adhesion over level 3

088:LC warn 88:Low conductivity Warning

089:Insu detect 89:Insulation detection

090:FLN over lv 3 90:Flow noise over level 3

091:FLN over lv 4 91:Flow noise over level 4

092:AZ warn 92:Autozero warning

093:Verif warn 93:Vericationwarning

094:Fact noise warn 94:Factory noise warning

095:Simulate active 95:Simulation active

098:Pls1x 98:Pulseoutput1xed

101:Param restore run 101:Parameter restore running -
