<5. Functions>
152
IM 01E21A02-03EN
Alarm Name
Restore or
Duplicate
Display F
OUNDATION Fieldbus
102:Disp over 102:Display over warning -
103:SD size warn 103:microSD card size warning -
104:Bkup incmplt 104:Parameter backup incomplete

105:SD mismatch 105:microSD card mismatch -
106:SD removal ERR 106:microSD card removal error -
120:Watchdog 120:Watchdog

121:Powero󰀨 121:Powero󰀨

122:Inst power FAIL 122:Instant power failure

123:Param bkup run 123:Parameter backup running -
124:Data log run 124:Data logging running -
131:Trans mismatch 131:Transmitter type mismatch -
133:G/A mismatch 133:G/A mismatch error -
225:Lnk.O16/32 N/O 225:Link Obj. 16/32 Not Open

226:Lnk.O15/31 N/O 226:Link Obj. 15/31 Not Open

227:Lnk.O14/30 N/O 227:Link Obj. 14/30 Not Open

228:Lnk.O13/29/45 N/O 228:Link Obj. 13/29/45 Not Open

229:Lnk.O12/28/44 N/O 229:Link Obj. 12/28/44 Not Open

230:Lnk.O11/27/43 N/O 230:Link Obj. 11/27/43 Not Open

231:Lnk.O10/26/42 N/O 231:Link Obj. 10/26/42 Not Open

232:Lnk.O9/25/41 N/O 232:Link Obj. 9/25/41 Not Open

233:Lnk.O8/24/40 N/O 233:Link Obj. 8/24/40 Not Open

234:Lnk.O7/23/39 N/O 234:Link Obj. 7/23/39 Not Open

235:Lnk.O6/22/38 N/O 235:Link Obj. 6/22/38 Not Open

236:Lnk.O5/21/37 N/O 236:Link Obj. 5/21/37 Not Open

237:Lnk.O4/20/36 N/O 237:Link Obj. 4/20/36 Not Open

238:Lnk.O3/19/35 N/O 238:Link Obj. 3/19/35 Not Open

239:Lnk.O2/18/34 N/O 239:Link Obj. 2/18/34 Not Open

240:Lnk.O1/17/33 N/O 240:Link Obj. 1/17/33 Not Open

244:Amp EEP FAIL 244:Amp EEPROM Failure

246:Simulate SW OFF 246:Simulation Switch OFF

247:RB O/S Mode 247:RB in O/S mode

248:Simulate SW ON 248:Simulation Switch ON

249:SoftDL Incmplt 249:SoftDL Incomplete

250:SoftDL FAIL 250:SoftDL Failure

251:Abnml Boot PRS 251:Abnormal Boot Process

252:HWrite Lock SW ON 252:Hard Write Lock SW ON

253:Write Locked 253:Write Locked

254:HWrite Lock SW OFF 254:Hard Write Lock SW OFF

255:Write Unlocked 255:Write Unlocked

300:AI1 O/S Mode 300:AI1 in O/S Mode

301:AI1 Man Mode 301:AI1 in Man Mode

302:AI1 Not Schedule 302:AI1 Not Scheduled

303:AI1 Simulate Act 303:AI1 Simulation Active

304:AI2 O/S Mode 304:AI2 in O/S Mode

305:AI2 Man Mode 305:AI2 in Man Mode

306:AI2 Not Schedule 306:AI2 Not Scheduled

307:AI2 Simulate Act 307:AI2 Simulation Active

308:AI3 O/S Mode 308:AI3 in O/S Mode

309:AI3 Man Mode 309:AI3 in Man Mode

310:AI3 Not Schedule 310:AI3 Not Scheduled

311:AI3 Simulate Act 311:AI3 Simulation Active

312:AI4 O/S Mode 312:AI4 in O/S Mode

313:AI4 Man Mode 313:AI4 in Man Mode

