YOKOGAWA ADMAG TI Series

<5. Functions>
158
IM 01E21A02-03EN
*2: From the table below, select the ending time of the data logging function.
Selection
Description
Display
F
OUNDATION
Fieldbus
10 min 10min Sets the ending time to 10 minutes later.
30 min 30min Sets the ending time to 30 minutes later.
1 h 1h Sets the ending time to 1 hour later.
3 h 3h Sets the ending time to 3 hours later.
12 h 12h Sets the ending time to 12 hours later.
24 h 24h Setstheendingtimeto24hours(1day)later.
72 h 72h Setstheendingtimeto72hours(3days)later.
240 h 240h Setstheendingtimeto240hours(10days)later.
720 h 720h Setstheendingtimeto720hours(30days)later.
1440 h 1440h Setstheendingtimeto1440hours(60days)later.
*3: From the table below, select the process value to be stored.
Selection
Description
Display
F
OUNDATION
Fieldbus
PV PV Stores the process value PV-mapped in Subsection 5.1.2.
Velocity Velocity Storestheowvelocity.
Volumeow Volumeow Storesthevolumetricowrate.
Massow Massow Storesthemassowrate.
Calorie Calorie Storesthecalorie(onlyavailableforAXG,notforAXW).
Flow noise Flow noise Storestheownoisevalue(onlyavailableforAXG,notforAXW).
Adhesion Adhesion Stores the resistance value of the electrode adhesion detection.
Electrode A Electrode A Stores the voltage of electrode A.
Electrode B Electrode B Stores the voltage of electrode B.
V peak V peak
Storesthepeakvalueoftheowratesignal(onlyavailableforAXG,not
forAXW).
*4: From the table below, select the use of the data logging function.
Selection
Description
Display
F
OUNDATION
Fieldbus
Not execute Not Execute Does not execute the data logging function.
Execute Execute Executes the data logging function.
SettingdataisstoredonthemicroSDcardataspecieddatastorageintervalduringaperiod
fromthestartofthedataloggingfunctiontotheend.Thelestoredwiththedataloggingfunction
canbeopenedasatextle.
Example:Ifthestorageintervalissetto“1min”,dataisstoredasshownbelow.
F0437.ai
…………
…………
Date and time
Process
value 1
Process
value 2
Process
value 3
Process
value 4
2017/01/0112:00:00
2017/01/0112:01:00
2017/01/0112:02:00
2017/01/0112:03:00
2017/01/0112:04:00
2017/01/0112:05:00
+9.9863E-01
+9.9909E-01
+9.9906E-01
+9.9859E-01
+9.9870E-01
+9.9829E-01
+2.8235E+01
+2.8248E+01
+2.8248E+01
+2.8234E+01
+2.8237E+01
+2.8226E+01
+1.4117E+04
+1.4124E+04
+1.4124E+04
+1.4117E+04
+1.4118E+04
+1.4113E+04
+4.5600E-01
+3.9717E-01
+3.1753E-01
+4.0430E-01
+3.6609E-01
+4.1892E-01
TheaccessongoingtothemicroSDcardcanbeconrmedwiththeicononthedisplay.For
example,theiconsofthe“microSDcardready”and“AccesstomicroSDcard”aredisplayed
alternately and repeatedly because the product accesses to the microSD card periodically during
its data logging.
