 List of selection for sensor transducer block parameter
Label
Value
Selection
Parameter Name Display
F
OUNDATION
Fieldbus
Display
F
OUNDATION
Fieldbus
SENSOR_CAL_
METHOD
Sensor Calibration
method
100 volumetric
101 static weigh
102 dynamic weigh
255 other
SELECTED_FLOW PVowselect Selected Flow 0 Velocity Velocity
1 Volume Volume
2 Mass Mass
SELECT_FLOW_
SENSOR
Flow sensor sel Select Flow Sensor 0 ADMAG AXG ADMAG AXG
1 ADMAG AXW ADMAG AXW
2 ADMAG AXF ADMAG AXF
4 ADMAG AE ADMAG AE
7 Calibrator Calibrator
8 Other 1 Other1
9 Other 2 Other2
10 Other 3 Other3
NOMINAL_SIZE_
UNIT
Nominal size unit Nominal Size Unit 0
1
mm
inch
mm
inch
AUTOZERO_
EXECUTE
Autozero►Execute Autozero Execute 0 Not execute Not execute
1 Execute Execute
SIGNAL_LOCK 0% signal lock Signal Lock 0 O󰀨 Unlock
1 On Lock
TOT1_F_OPTS Totalizer1►
Failure opts
Total 1 Failure Opts 0 Measured value Measured value
TOT2_F_OPTS Totalizer2►
Failure opts
Total 2 Failure Opts 1 Stop Stop
2 Last valid Last valid
TOT1_OPTS Totalizer1►Options Total 1 Options 0 Balanced Balanced
TOT2_OPTS Totalizer2►Options Total 2 Options 1 Absolute Absolute
2 Only positive OnlyPositive
3 Only negative OnlyNegative
4 Hold Hold
TOT1_EXEC Totalizer1►Start/Stop Total 1 Execution 0 Stop Stop
TOT2_EXEC Totalizer2►Start/Stop Total 2 Execution 1 Start Start
TOT1_PRESET Totalizer1►
Reset/Preset
Total 1 Preset 0 Not execute Not execute
TOT2_PRESET Totalizer2►
Reset/Preset
Total 2 Preset 1 Reset Reset
2 Preset Preset
TEMPERATURE_
FUNC
Temperature►
Function
Temp Function 0 No function No function
1 Monitoring Monitoring
2 Di󰀨temperature Di󰀨temperture
3 Temperature Ext temperature
TEMPERATURE_
UNIT
Temperature►Unit Temp Unit 0 °C °C
1 °F °F
2 K K
FLOW_DIRECT Flow direct Flow Direction 0 Forward Forward
1 Reverse Reverse
NOISE_FILTER Noiselter Noise Filter 0 Manual Manual
1 Level 1 Level 1
2 Level 2 Level 2
3 Level 3 Level 3
