YOKOGAWA ADMAG TI Series

<Appendix 2. Integrator (It) Block>
252
IM 01E21A02-03EN
Index
Parameter
Name
Default
Value
Write
Mode
View
Description
1 2 3 4
28 INTEG_TYPE
UP_AUTO
(1)
1
Integration Type Setting
Value Name Description
1 UP_AUTO
Counts up and is
automatically reset
when TOTAL_SP is
reached.
2 UP_DEM
Counts up and is reset
as demanded.
3 DN_AUTO
Counts down and is
automatically reset
when“0”isreached.
4 DN_DEM
Counts down and is
reset as demanded.
5 PERIODIC
Counts up and is reset
atperiodsspeciedin
CLOCK_PER.
6 DEMAND
Counts up and is reset
as demanded.
7 PER&DEM
Resets periodically or
as demanded.
