<Appendix 2. Integrator (It) Block>
253
IM 01E21A02-03EN
Index
Parameter
Name
Default
Value
Write
Mode
View
Description
1 2 3 4
29 INTEG_OPTS 030004 2
Speciesanintegrationoptionalfunction.
bit
Option
Name
Description
0
Input 1
accumulate
Selects RATE or
ACCUM input of IN_1.
1
Input 2
accumulate
Selects RATE or
ACCUM input of IN_2.
2
Flow
forward
Integratesforwardow
(interpretsreverseow
aszero).*
3
Flow
reverse
Integratesreverseow
(interpretsforwardow
aszero).*
4
Use
uncertain
Uses the input value
of IN_1 or IN_2 whose
statusis“Uncertain”
regarding it as a value
of“Good”.
5 Use bad
Uses the input value
of IN_1 or IN_2
whosestatusis“Bad”
regarding it as a value
of“Good”.
6 Carry
Carries over an excess
exceeding the threshold
at reset to the next
integration.
(Notethatthisdoesnot
apply to UP_AUTO or
DN_AUTO.)
7
Add zero if
bad
Interprets an increment
as zero if the status of
theincrementis“Bad”.
8
Conrm
reset
After reset, rejects
the next reset until
“Conrm”issetto
RESET_CONFIRM.
9
Generate
reset event
Generates an alert
event at reset.
10 to
15
Reserved
*Ifbothforwardandreverseowsareenabled
ordisabled,bothforwardandreverseows
are integrated.
30 CLOCK_PER 86400.0[sec] 4
Speciestheperiodatwhichaperiodicreset
is made.
31 PRE_TRIP 100000.0 4
Speciesanallowanceappliedbeforean
integrated value exceeds the setpoint.
32 N_RESET 0.0 4 4
Indicates the number of resets in the range of
0 to 999999.
33 PCT_INCL 0.0[%] 4 4
The ratio of “the integrated values of the
absolute values of the increments whose
statusisGood”tothe“integratedvaluesofthe
absolute values of the increments irrelevant
tothestatus”PCT_INCL=100x(1−(mspof
RTotal)/mspofATotal))
34 GOOD_LIM 0.0[%] 4
The threshold of the ratio of “the integrated
values of the increments whose status is
Good”toallintegratedvaluesinwhichthe
statusofOUTis“Good”
