<5. Functions>
74
IM 01E21A02-03EN
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 146 -- Lmt Sts Cal2 Hys
Speciesthehysteresisofcalorielimit
switch 2.
STB 147 -- Lmt Sts Cal2 Unit Displays the unit of the calorie.
 Adhesion limit switch
Display --
F
OUNDATION
Fieldbus
DeviceConguration►DTB►DeviceConguration►Conguration►LimitSwitch
Adhesion1►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
DTB 58
--
Lim.Sw.Adhesion1Value►
Lmt Sts Adh1.Status
Displays the status of the contact point
output of adhesion limit switch 1.
--
Lim.Sw.Adhesion1Value►
Lmt Sts Adh1.Value
Displays the contact point output of
adhesion limit switch 1.
DTB 59 -- Lmt Sts Adh1 Sp
Speciesthethresholdofadhesionlimit
switch 1.
DTB 60 -- Lmt Sts Adh1 Act Dir
Speciestheoperationdirectionof
adhesion limit switch 1.
DTB 61 -- Lmt Sts Adh1 Hys
Speciesthehysteresisofadhesionlimit
switch 1.
DTB 62 -- Lmt Sts Adh1 Unit Displays the unit of the adhesion.
Display --
F
OUNDATION
Fieldbus
DeviceConguration►DTB►DeviceConguration►Conguration►LimitSwitch
Adhesion2►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
DTB 63
--
Lim.Sw.Adhesion2Value►
Lmt Sts Adh2.Status
Displays the status of the contact point
output of adhesion limit switch 2.
--
Lim.Sw.Adhesion2Value►
Lmt Sts Adh2.Value
Displays the contact point output of
adhesion limit switch 2.
DTB 64 -- Lmt Sts Adh2 Sp
Speciesthethresholdofadhesionlimit
switch 2.
DTB 65 -- Lmt Sts Adh2 Act Dir
Speciestheoperationdirectionof
adhesion limit switch 2.
DTB 66 -- Lmt Sts Adh2 Hys
Speciesthehysteresisofadhesionlimit
switch 2.
DTB 67 -- Lmt Sts Adh2 Unit Displays the unit of the adhesion.
