YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
75
IM 01E21A02-03EN
 Voltage limit switch between electrode A and electrode C
Display --
F
OUNDATION
Fieldbus
DeviceConguration►DTB►DeviceConguration►Conguration►LimitSwitch
ElectrodeA1►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
DTB 68
--
Lim.Sw.ElectrodeA1Value►
Lmt Sts Elec A1.Status
Displays the status of the contact point
output of voltage limit switch 1 between
electrode A and electrode C.
--
Lim.Sw.ElectrodeA1Value►
Lmt Sts Elec A1.Value
Displays the contact point output of
voltage limit switch 1 between electrode A
and electrode C.
DTB 69 -- Lmt Sts Elec A1 Sp
Speciesthethresholdofvoltagelimit
switch 1 between electrode A and
electrode C.
DTB 70 -- Lmt Sts Elec A1 Act Dir
Speciestheoperationdirectionof
voltage limit switch 1 between electrode A
and electrode C.
DTB 71 -- Lmt Sts Elec A1 Hys
Speciesthehysteresisofvoltage
limit switch 1 between electrode A and
electrode C.
DTB 72 -- Lmt Sts Elec A1 Unit
Displays the unit of the voltage between
electrode A and electrode C.
Display --
F
OUNDATION
Fieldbus
DeviceConguration►DTB►DeviceConguration►Conguration►LimitSwitch
ElectrodeA2►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
DTB 73
--
Lim.Sw.ElectrodeA2Value►
Lmt Sts Elec A2.Status
Displays the status of the contact point
output of voltage limit switch 2 between
electrode A and electrode C.
--
Lim.Sw.ElectrodeA2Value►
Lmt Sts Elec A2.Value
Displays the contact point output of
voltage limit switch 2 between electrode A
and electrode C.
DTB 74 -- Lmt Sts Elec A2 Sp
Speciesthethresholdofvoltagelimit
switch 2 between electrode A and
electrode C.
DTB 75 -- Lmt Sts Elec A2 Act Dir
Speciestheoperationdirectionof
voltage limit switch 2 between electrode A
and electrode C.
DTB 76 -- Lmt Sts Elec A2 Hys
Speciesthehysteresisofvoltage
limit switch 2 between electrode A and
electrode C.
DTB 77 -- Lmt Sts Elec A2 Unit
Displays the unit of the voltage between
electrode A and electrode C.
