<5. Functions>
76
IM 01E21A02-03EN
 Voltage limit switch between electrode B and electrode C
Display --
F
OUNDATION
Fieldbus
DeviceConguration►DTB►DeviceConguration►Conguration►LimitSwitch
ElectrodeB1►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
DTB 78
--
Lim.Sw.ElectrodeB1Value►
Lmt Sts Elec B1.Status
Displays the status of the contact point
output of voltage limit switch 1 between
electrode B and electrode C.
--
Lim.Sw.ElectrodeB1Value►
Lmt Sts Elec B1.Value
Displays the contact point output of
voltage limit switch 1 between electrode B
and electrode C.
DTB 79 -- Lmt Sts Elec B1 Sp
Speciesthethresholdofvoltagelimit
switch 1 between electrode B and
electrode C.
DTB 80 -- Lmt Sts Elec B1 Act Dir
Speciestheoperationdirectionof
voltage limit switch 1 between electrode B
and electrode C.
DTB 81 -- Lmt Sts Elec B1 Hys
Speciesthehysteresisofvoltage
limit switch 1 between electrode B and
electrode C.
DTB 82 -- Lmt Sts Elec B1 Unit
Displays the unit of the voltage between
electrode B and electrode C.
Display --
F
OUNDATION
Fieldbus
DeviceConguration►DTB►DeviceConguration►Conguration►LimitSwitch
ElectrodeB2►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
DTB 83
--
Lim.Sw.ElectrodeB2Value►
Lmt Sts Elec B2.Status
Displays the status of the contact point
output of voltage limit switch 2 between
electrode B and electrode C.
--
Lim.Sw.ElectrodeB2Value►
Lmt Sts Elec B2.Value
Displays the contact point output of
voltage limit switch 2 between electrode B
and electrode C.
DTB 84 -- Lmt Sts Elec B2 Sp
Speciesthethresholdofvoltagelimit
switch 2 between electrode B and
electrode C.
DTB 85 -- Lmt Sts Elec B2 Act Dir
Speciestheoperationdirectionof
voltage limit switch 2 between electrode B
and electrode C.
DTB 86 -- Lmt Sts Elec B2 Hys
Speciesthehysteresisofvoltage
limit switch 2 between electrode B and
electrode C.
DTB 87 -- Lmt Sts Elec B2 Unit
Displays the unit of the voltage between
electrode B and electrode C.
