YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
93
IM 01E21A02-03EN
NE
107
Error Message
Error Description Countermeasure FD bit
Display
F
OUNDATION
Fieldbus
N 375:AI3 Lo Alarm AI3 Low Alarm
Low alarm occurred in
the AI3 block.
Check AI3 Output
Value and settings of
AI3 Lo Lim and AI3 Lo
Pri.
7 0
N 376:AI4 HH Alarm AI4 High High Alarm
HI_HI alarm occurred
in the AI4 block.
Check AI4 Output
Value and settings of
AI4 HiHi Lim and AI4 Hi
Hi Pri.
8 31
N 377:AI4 LL Alarm AI4 Low Low Alarm
LO_LO alarm occurred
in the AI4 block.
Check AI4 Output
Value and settings of
AI4 LoLo Lim and AI4
Lo Lo Pri.
8 30
N 378:AI4 Hi Alarm AI4 High Alarm
High alarm occurred in
the AI4 block.
Check AI4 Output
Value and settings of
AI4 Hi Lim and AI4 Hi
Pri.
8 29
N 379:AI4 Lo Alarm AI4 Low Alarm
Low alarm occurred in
the AI4 block.
Check AI4 Output
Value and settings of
AI4 Lo Lim and AI4 Lo
Pri.
8 28
N 392:PID HH Alarm PID High High Alarm
HI_HI alarm occurred
in the PID block.
Check PID Output
Value and settings of
PID HiHi Lim and PID
Hi Hi Pri.
8 27
N 393:PID LL Alarm PID Low Low Alarm
LO_LO alarm occurred
the PID block.
Check PID Output
Value and settings of
PID LoLo Lim and PID
Lo Lo Pri.
8 26
N 394:PID Hi Alarm PID High Alarm
High alarm occurred in
the PID block.
Check PID Output
Value and settings of
PID Hi Lim and PID
Hi Pri.
8 25
N 395:PID Lo Alarm PID Low Alarm
Low alarm occurred in
the PID block.
Check PID Output
Value and settings of
PID Lo Lim and PID
Lo Pri.
8 24
 Setting alarm
The device works normally, but the parameter setting error occurs.
Parameter setting is needed.
NE
107
Error Message
Error Description Countermeasure FD bit
Display
F
OUNDATION
Fieldbus
S 060:Span cfg ERR
Spanconguration
error
Setting error of span
owratewasdetected.
(fulll“0.05m/s<span
owrate<16m/s”)
Check or change span
parameter settings.
3 23
S 066:Density cfg ERR
Density
congurationerror
The setting error of
density value was
detected when PV was
settomassowrate.
Check the parameter
settings related to
density.
3 17
S 067:Pls 1 cfg ERR
Pulse output 1
congurationerror
Setting error of pulse
output 1 was detected.
Check Pulse1-related
parameter settings.
3 15
