YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
94
IM 01E21A02-03EN
NE
107
Error Message
Error Description Countermeasure FD bit
Display
F
OUNDATION
Fieldbus
C 069:Nomi size cfg
Nominal size
congurationerror
Congurationerror
of nominal size was
detected.
(fulll“0.99mm<
nominal size of sensor
<3000.10mm(0.01
inch<nominalsizeof
sensor<120.10inch)”)
Check the parameter
settings related to
nominal size.
3 13
C 070:Adh cfg ERR
Adhesion
congurationerror
Setting error of
electrode adhesion
detection function was
detected.
(fulll“Level1<Level2
<Level3<Level4”)
Check the parameter
settings related to
adhesion detection.
3 12
C 071:FLN cfg ERR
Flow noise
congurationerror
Settingerrorofow
noiseverication
function was detected.
(fulll“Level1<Level2
<Level3<Level4”)
Changeownoise
parameter settings.
3 11
C 072:Log not start
Data logging not
started
Data logging failed to
start.
Insert the microSD
card.
3 10
C 247:RB O/S Mode RB in O/S Mode
Resource block is in
the O/S mode.
Change it to AUTO
mode.
1 22
C 300:AI1 O/S Mode AI1 in O/S Mode
The AI1 block is in the
O/S mode.
Change the AI1 block
mode.
6 31
C 301:AI1 Man Mode AI1 in Man Mode
The AI1 block is in the
Man mode.
Change the AI1 block
mode.
6 30
C 302:AI1 Not Schedule AI1 Not Scheduled
AI1 block is
unscheduled.
Schedule the AI1 block. 6 29
C 303:AI1 Simulate Act
AI1 Simulation
Active
AI1 simulation function
is running.
Disable SIMULATE.
Simulate En/Disable of
the AI1 block.
6 28
C 304:AI2 O/S Mode AI2 in O/S Mode
The AI2 block is in the
O/S mode.
Change the AI2 block
mode.
6 27
C 305:AI2 Man Mode AI2 in Man Mode
The AI2 block is in the
Man mode.
Change the AI2 block
mode.
6 26
C 306:AI2 Not Schedule AI2 Not Scheduled
AI2 block is
unscheduled.
Schedule the AI2 block. 6 25
C 307:AI2 Simulate Act
AI2 Simulation
Active
AI2 simulation function
is running.
Disable SIMULATE.
Simulate En/Disable of
the AI2 block.
6 24
C 308:AI3 O/S Mode AI3 in O/S Mode
The AI3 block is in the
O/S mode.
Change the AI3 block
mode.
6 23
C 309:AI3 Man Mode AI3 in Man Mode
The AI3 block is in the
Man mode.
Change the AI3 block
mode.
6 22
C 310:AI3 Not Schedule AI3 Not Scheduled
AI3 block is
unscheduled.
Schedule the AI3 block. 6 21
C 311:AI3 Simulate Act
AI3 Simulation
Active
AI3 simulation function
is running.
Disable SIMULATE.
Simulate En/Disable of
the AI3 block.
6 20
C 312:AI4 O/S Mode AI4 in O/S Mode
The AI4 block is in the
O/S mode.
Change the AI4 block
mode.
6 19
C 313:AI4 Man Mode AI4 in Man Mode
The AI4 block is in the
Man mode.
Change the AI4 block
mode.
6 18
C 314:AI4 Not Schedule AI4 Not Scheduled
AI4 block is
unscheduled.
Schedule the AI4 block. 6 17
C 315:AI4 Simulate Act
AI4 Simulation
Active
AI4 simulation function
is running.
Disable SIMULATE.
Simulate En/Disable of
the AI4 block.
6 16
C 328:PID O/S Mode PID in O/S Mode
The PID block is in the
O/S mode.
Change the PID block
mode.
6 15
