YOKOGAWA MW100 User Manual

3-2
IM MW100-01E
3.1 Connection Environment
MW100 Operation Screens
The operation screens of the MW100 main module consist of Monitor screens enabling
operations in Measurement mode, Setting screens that are mainly used in Setting mode,
and Status screens for mode changes.
Top Screen
• Monitor
Single Screen, Dual Screen
• Setting
Channel Setting, System Setting, Display Setting, Communication Setting
• Status
Measurement, MATH, and Recording status changes
When entering settings, the pages for all setting items are displayed, but there may be
settings or items that cannot be entered depending on the installed modules and options.
Single Screen and Dual Screens
Monitor-displays the data from the MW100.
For details on the operation, see section 3.16, “Measured Data Monitor Display/Settings.”
Channel Setting
You can set the measurement range, expressions, and other items.
