1-46
IM MW100-01E
Steady Output Operation
Output Operation When Connected for Communication
Communication Connection Status Output Operation
Normal connection (initial connection after power ON) Operation when power is turned ON
Communications opened successfully Holds the output value (last output value)
(when communications were cut and restored for the 2nd or more time)
Communication disconnected successfully Holds the output value (last output value)
Output Operation during Measurement and When Performing Transmission
Output
“Transmission output execution ON” in the table is when the transmission output control is ON.
“Transmission output execution OFF” in the table is when the transmission output control is OFF.
Output Setup Status Output Operation
Transmission Meas. stop Measurement start Transmission output start or output value
output within hold (depending on the transmission output
unit execution on/off status
on: transmission output starts
off: output value held)
Measuring Measurement stop Holds the output value (last output value)
Measuring Transmission output execution off on Transmission start
Transmission output execution on off Holds output value (last output value)
Arbitrary Meas. stop Measurement start No effect
output
Measuring Measurement stop No effect
Measuring Transmission output execution off on No effect
Transmission output execution on off No effect
Output Operation during an Abnormality and after Recovery from the Abnormality
Output Operation during an Abnormality (by Module)
Abnormal Module Display Status Output Operation
Main module b
F
*
System errors Operation when power is turned ON
bF Dip switches
F0 ROM error
F1 SRAM error
F2 EEPROM error
F3 Battery error
F4 Ethernet error
Output modules U0 Range information error Operation when power is turned ON or
U1 Calibration value error
when output value uncertain
U2 Error during calibration Internal communication error occurred,
resulting in an error recovery event. If
the error recovery time is 10 s or more,
output is performed per the operation for
U3 Error in writing the
error occurrence, and then output is
calibration value.
executed per the operation for power ON.
U4 Unusable modules Operation when power is turned ON or
when output value uncertain
Input modules U0 Range information error Operation when errors occur (transmission
U1 Calibration value error
between units output only, since the
U4 Unusable modules
transmission source input channel is
illegal**)
* The number corresponding to the error is shown in the
F
.
** Illegal occurs when a module is removed, when a module recognition fails, or when a module
malfunctions.
1.11
Operation of the 8-CH Medium-Speed Analog Output Module and the 8-CH Medium Speed PWM Output Module
