4-18
IM MW100-01E
4.6 System Initialization
Perform this procedure to initialize the settings on the MW100. The following types of
initialization are available.
Initialization Type
Type Level Items Initialized
Initialization using dip switches ---- All settings
Initialization using All Setting other than configurated module
communication commands information
All except Comm. Settings excluding the following items
(IP address, host name, subnet mask, default
gateway, DHCP parameters, DNS parameters,
communication timeout parameters, login
parameters, baud rate, parity bit, stop bit, data
length, handshaking, and module recognition
information)
Initialization Procedure
Using Dip Switches
1.
Turn OFF the power to the MW100.
2.
Check that the switch 5 of dip switch 1 on the main module is OFF.
12345678
ON
3.
Turn OFF the power to the MW100.
After the 7-segment LED indicates the power ON self check, bF is displayed.
4.
Check the status of step 3, then turn the power OFF.
5.
Turn switch 5 of dip switch 1 ON.
Initialization using communication commands
Using a Browser
For information about initialization using communication command, see the MW100
Communication Command manual (IM MW100-17E).
1.
From the top screen, click System Settings > Module Information under the
Top item.
2.
Select the initialization level from the Initialization Level box under System
information.
3.
Click the Initialize button. Initialization is performed.
For a description of the operation screen for initialization, see section 3.3, “System Settings.”
To Next Page
