IM MW100-01E
Foreword
Thank you for purchasing the MW100 Data Acquisition Unit. This user’s manual contains
useful information about the instrument’s functions, installation and wiring procedures,
operating procedures, and handling precautions. To ensure correct use, please read
this manual thoroughly before beginning operation. The five manuals below are also
provided in addition to this manual. Read them along with this manual. As with this
manual, the MW100 Viewer Software User’s Manual (IM MW180-01E) and the MW100
Communication Command Manual (IM MW180-01E) are included in the accompanying
CD-ROM.
Manual Title Manual No. Description
MW100 Data Acquisition IM MW100-02E Describes concisely the handling of the
Unit Operation Guide MW100 Data Acquisition Unit and the basic
operations of the MW100 Viewer Software.
Precautions on the Use of IM MX100-71E Summarizes the precautions regarding the use
the MX100/MW100 of the MW100 Data Acquisition Unit.
Data Acquisition Unit
MX100/MW100 Data Acquisition IM MX100-72E Describes concisely the installation procedures
Unit Installation and and wiring procedures of the MW100 Data
Connection Guide Acquisition Unit.
MW100 Viewer Software IM MW180-01E Describes the functions and operations of the
User’s Manual MW100 Viewer Software that comes
standard with the MW100 main module.
MW100 Communication IM MW100-17E Describes the communication command of the
Command Manual MW100 main module.
Notes
This manual describes the MW100 Data Acquisition Unit, style number “S2.” Check the
style number on the name plate of the main module (see page iv for the location of the
name plate).
• The contents of this manual are subject to change without prior notice as a result of
continuing improvements to the instrument’s performance and functions.
• Every effort has been made in the preparation of this manual to ensure the accuracy
of its contents. However, should you have any questions or find any errors, please
contact your nearest YOKOGAWA representative, dealer, or sales office.
• Copying or reproducing all or any part of the contents of this manual without the
permission of Yokogawa Electric Corporation is strictly prohibited.
• The TCP/IP software of this product and the document concerning the TCP/IP software
have been developed/created by YOKOGAWA based on the BSD Networking Software,
Release 1 that has been licensed from the University of California at Berkeley.
Trademarks
• Microsoft and Windows are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
• Adobe and Acrobat are trademarks of Adobe Systems incorporated.
• Java and logomark are are either registered trademarks or trademarks of
Sun Microsystems Inc. in the United States and/or other countries.
• CompactFlash is a registered trademark of Sundisk Corporation in the USA, and
licensed from the CFA (Compact Flash Association).
• For purposes of this manual, the ™ and ® symbols do not accompany their respective
trademark names or registered trademark names
• Company and product names that appear in this manual are trademarks or registered
trademarks of their respective holders.
Revisions
1st Edition: June, 2005
2nd Edition: October, 2006
2nd Edition : October 2006 (YK)
All Rights Reserved, Copyright © 2005 Yokogawa Electric Corporation
