5-38
IM MW100-01E
General Specifications
Operating temperature range: –20 to 60°C
Operating humidity range: 20 to 80% RH for –20 to 40 °C
10 to 50% RH for 40 to 50°C
5 to 30% RH for 50 to 60 °C
External Dimensions
Units: mm
57
150.8
131
If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the
tolerance is ±0.3 mm.
5.6 6-CH, Medium-Speed Four-Wire RTD Resistance Input Module Specifications
