Starting Communication
Starting Measurement and Computation
MATH channels must be displayed to show transmitted data. After starting measurement,
start computation.
Displaying Data
When data is sent/received via Modbus communication, the following waveform is
displayed on the monitor screen of a Web browser.
• Displaying MW100 Client Data (Trend)
Computed data (data received via Modbus communications)
• Displaying MW100 Server Data (Trend)
Measured data Computed data (data received via Modbus communications)
Appendix 2 Setting Data Communication That Uses Modbus Protocol
