YOKOGAWA MW100 User Manual

App-21
IM MW100-01E
Appendix
App
Replacing the CF Card While Recording
You can replace the CF card while recording is in progress. Replace the CF card while
the access indication to the CF card is not showing. An access forewarning is indicated
before the CF card is accessed.
The data save operation when the card is replaced between data write intervals is as
follows:
CF card 1
CF card 2
Time (s)
Start
Length of one data writing
File 1
File 2 File 3
Data write time
Replace the CF card
* For Fullstop
If the data write interval arrives while the CF card is being replaced (CF card removed
from the MW100), the write length of data drops out.
The data save operation if the data write interval arrives while the CF card is being
replaced is as follows:
CF card 1
CF card 2
Time (s)
Start
Length of one
data writing
File 1
File 2 File 3
Data write time
Remove the CF
card
Write length of data drops out because the
data could not be written
* For Fullstop
Insert the CF card
The files that are divided due to the replacement of the CF card can be joined using
the MW100 Viewer Software. The files that can be joined are limited those in which the
recording start action is Direct. It is possible to join files even if there are dropouts. For
details, see the MW100 Viewer Software User’s Manual (MW180-01E).
Appendix 8 Saving Data to the CF Card
