1-34
IM MW100-01E
DI
Measurement Range Notation Rated Measurement Range
LEVEL LEVEL Vth=2.4 V
Contact input CONTACT 1 k or less, ON, 100 k or less, OFF
(shunt capacitance: 0.01 µF or less)
Measurement Interval, Integration Time, and Filter
You can select from the following measurement intervals for this module.
100 ms, 200 ms, 500 ms, 1 s, 2 s, 5 s, 10 s, 20 s, 30 s, 60 s
The integral time and types of filters applied vary depending on the measurement
interval. For details, see section 2.9, “Measures against Noise on the MW100 Data
Acquisition Unit.”
If the measurement interval is 100 ms, burnout detection is performed on one channel
during one measurement interval. After measurement starts when in the burnout
condition, or after the burnout, burnout detection is disabled for up to ten measurements
(approximately one second).
Measurement Synchronization
Since measurement is sequential, measurement on each channel is not synchronized.
1.5 Functions of the 10-CH, Medium-Speed Universal Input Module
