YOKOGAWA MW100 User Manual

3-13
IM MW100-01E
Setting and Data acquisiton
3
3.3 System Settings
Setting Mode
System Reconstruction
When connecting the MW100 for the first time, or when changing the position of an
installed input/output module on the connected MW100, system reconfiguration is
performed (to match up with the actual modules). Before reconfiguration, connect to the
MW100 to be reconfigured.
Note
Always turn the power to the MW100 OFF before attaching or removing input/output modules.
Setting Module Information
1.
From the top page, click System Setting > Module Information.
2.
If the Configured Module and Attached Module boxes are different, click the
Reconstruct button to reconfigure the system.
Setting the Date and Time
Sets the date and time on the MW100.
1.
From the top page, click System Setting > Date and Time.
2.
Enter the year, month, and date in the Date box. Use the last two digits of the
Western calendar for the year.
3.
Enter the hour, minute, and second in the Time box. Time is specified in 24-hour
format.
4.
Enter the hour and minutes in the Time Zone box.
5.
Click the Apply button. The setting changes take effect.
