3-16
IM MW100-01E
Rate of Change Interval
1.
Enter the measurement count that determines the interval in the Increase
Interval box under Rate-of-Change Alarm.
2.
Enter the measurement count that determines the interval in the Decrease
Interval box under Rate-of-Change Alarm.
3.
Click the Apply button. The settings for each item are applied.
For a description of the rate of change interval, see “Alarms” in section 1.3.
Status Information and Processing
You can change the MW100 operation mode, operate the main unit keys, and check
alarm statuses.
Changing Status Information (Mode)
From the top screen, click System Setting > Status Information. You can perform the
same procedure in the Status table in the top screen.
• Switching between Measurement Mode and Setting Mode
1
In the Operation box under Measurement, you can select Start to switch to
Measurement mode, or Stop to switch to Setting mode.
2.
Click the Apply button. The changed status is displayed in the Status display
box.
• Computation Start/Stop
1
In the Operation box under the MATH item, you can select Start to start
computation, or Stop to stop computation.
2.
Click the Apply button. The changed status is displayed in the Status display
box. You can also start and stop computation from the Monitor screen.
• Recording Start/Stop
1
In the Operation box under the Recording item, you can select Start to start
recording, or Stop to stop recording.
2.
Click the Apply button. The changed status is displayed in the Status display
box. You can also start and stop recording from the Monitor screen.
Checking Status Information
When an alarm occurs, Waiting Alarm ACK is displayed in each display box.
3.3 System Settings
To Next Page
