1-18
IM MW100-01E
Action Notation Detection Method
Edge Level
Write message Message1
on specified number Message2
Message3
Message4
Message5
Save specified file** File Save
Load specified file** File Load
* Cannot be selected when the event is Recording start.
** Cannot be selected when the event is User function key. The name of the target file is fixed to
SETTING.PNL.
Event detection methods*
Method Notation Description
Edge Edge Edge event
Level Level Level event
* The following limitations exist on the setting.
• You cannot set the same action type for Edge and Level. The following action types are
considered the same.
Memory Start and Memory Stop
MATH Start and MATH Stop
Flag with the same flag number
• You cannot set the same action type for different levels. The following action types are
considered the same.
Memory Start and Memory Stop
MATH Start and MATH Stop
Flag with the same flag number
The setting error above occurs when you switch from Setting Mode to Measurement Mode.
Daylight saving time
The internal clock is updated every specified month, week, day, and time.
Timer
The Event/Action function can be started according to timer settings.
The following two timers are available.
Type Notation Description
Relative Time Timer Relative Time up occurs at the specified time interval
Absolute Time Timer Absolute Time up occurs at a time interval after a specified
reference time**
* Operation upon power failure differs. For details, see “Timer” in section 5.2.
** Also valid prior to the reference time.
Match Time
The Event/Action function can be started according to the match time setting.
The following three match times are available.
Type Notation Description
Monthly Month Time up occurs every month on specified date and time (hr and min)
Weekly Week Time up occurs every every week on the specified day of the week and
time (hr and min)
Daily Day Time up occurs every day at the specified time (hr and min)
* Conditions can be set for no operation. For details, see “Match Time” in section 5.2.
** For information about operation during power failures and time changes, see “Match Time” in
section 5.2.
1.3 Functions of the Main Module
