Setting and Data acquisiton
3
Setting the Pulse Resolution
5.
Select the pulse resolution in the Range box.
Span Setting
Select the actual output range from the allowed output range.
6.
Enter the lower limit of span in the Lower box under Span. Also, enter the upper
limit value in the Upper box.
Pulse Interval
7.
In the Pulse Interval box, enter a coefficient that determines the pulse interval.
For a description of the pulse interval coefficient, see “Pulse Interval” in section 1.10.
Preset Value
8.
In the Preset Value box, enter a preset value for the output operation when
turning on the power or when an error occurs. When a preset value is selected in
the output operation settings, the specified value is output.
For the procedure to set the output operation, see “Output Operation Settings” in this
section.
For a description of preset values, see “Output upon Startup and Error Occurrence” in
section 1.11.
Reference Channel Settings
This is set if Trans is selected for the output method.
9.
Enter an input channel or MATH channel for transmission output in the Ref.
Channel box.
10.
Click the Apply button. The setting changes take effect.
Global Channel Settings
If the setting items of channels are the same, the settings of the first channel can be
applied collectively to the specified range. The setting range of channels is 001 to 060.
The specified range of channels must be analog output modules only or PWM output
modules only.
For a description of the global setting of channels, see “Global Channel Settings” in section
3.5.
3.9 Analog/PWM Output Settings
