3-44
IM MW100-01E
Starting and Stopping Computation
This function is enabled when the MATH function (/M1) option is installed. You can use
the function when MATH channels are set.
Using Main Module Keys
• Computation Start
While recording is stopped, and during measurement, briefly press the START key.
Computation starts.
• Computation Stop
During computation, and while recording is stopped, briefly press the STOP key.
Computation stops.
Using a Browser (in the Setting Screen)
The main module can be switched to Measurement mode. This is done while recording is
stopped.
• Starting Computation
In the Status table in the top screen, select Start from the Operation list of the MATH
item. Computation starts.
• Stopping Computation
In the Status table in the top screen, select Stop from the Operation list of the MATH
item. Computation stops.
You can also start or stop the computation from the Monitor screen.
For the procedure to start or stop the computation in the Monitor screen, see section 3.15,
“Measured Data Monitor Display/Settings.”
Starting and Stopping Recording
Using Main Module Keys
• Starting Recording
During measurement, hold down the START key for two or more seconds. Recording
starts.
• Stopping Recording
During recording, hold down the STOP key for two or more seconds. Recording stops.
Using a Browser (in the Setting Screen)
The main module can be switched to Measurement mode.
• Starting Recording
In the Status table in the top screen, select Start from the Operation list of the
Recording item. Recording starts.
• Stopping Recording
In the Status table in the top screen, select Stop from the Operation list of the
Recording item. Recording stops.
You can also start or stop the recording from the Monitor screen.
For the procedure to start or stop the recording in the Monitor screen, see section 3.15,
“Measured Data Monitor Display/Settings.”
3.12 Starting and Stopping Measurement, Computation, and Recording
