5-1
IM MW100-01E
Specification
5
Chapter 5 Specification
5.1 Common Specifications
Normal Operating Conditions
Rated power supply voltage: AC power supply (with or without AC adapter): 100 to 240 VAC
DC power supply: 12 to 28 VDC
Supply voltage range used: AC power supply (with or without AC adapter): 100 to 250
VAC
DC power supply: 10 to 32 VDC
Power supply frequency: 50 Hz ±2%, 60 Hz ±2%
Power consumption: AC power, or DC power with AC adapter: Approx. 70 VA
max.
DC power supply: Approx. 35 VA max.
* When any six I/O modules are installed
Vibration: 10 to 60 Hz 0.2m/s
2
or less
Shock: Not allowed
Magnetic fi eld: 400 A/m or less (50/60 Hz)
Position: Position horizontally with feet down
Structure: Not explosion-proof
Usage location: Indoors
Operating altitude: 2,000 m or less
Overvoltage category: II (per IEC61010-1 CSA22.2 No. 61010-1)
Measurement category: II (per IEC61010-1 CSA22.2 No. 61010-1)
Pollution degree: 2 (per IEC61010-1 CSA22.2 No. 61010-1)
Transport and Storage Conditions
Environmental conditions during transport and storage:
Ambient storage temperature : –25 to 70°C
Ambient storage humidity: 5% to 95% RH (no condensation)
Vibration: 10 to 60 Hz 4.9m/s
2
or less
Shock: 392 m/s
2
or less (packaged condition)
Mechanical Specifications (Excluding AC Adapter)
External dimensions: Approx. 455 × 131 × 159 mm (when six slots are attached)
Weight: Approx. 4.3 kg (maximum total weight)
Installation method: Desktop or fl oor, panel mount, or attached to a DIN rail
Material: Steel plate, aluminum die-cast, molded plastic resin
Standards Compliance
CSA: CSA22.2 No 61010-1, overvoltage category II, measurement
category II, pollution degree 2
UL: Conforms to UL61010B-1 (CSA NRTL/C)
CE: EMC directive; EN61326
EN61000-3-2
EN61000-3-3
Low voltage directive; EN61010-1; overvoltage category II,
measurement category II,
pollution degree 2
C-Tick: Conforms with AS/NZS CISPR11 Class A Group1
Overvoltage category II: An index for defi ning transient overvoltages (includes the
rated impulse withstand voltage, and applies to electrical
equipment supplied with power from fi xed installations such as
a distribution board).
Pollution degree 2: The degree of adherence by a solid, liquid, or vapor that
reduces the withstand voltage or surface resistance factor
(applies only to normal indoor atmospheres (with non-
conductive pollution).
Measurement category II: For measurements performed on circuits directly connected
to the electrical distribution system such as provided by a wall
outlet.
