YOKOGAWA MW100 User Manual

1-17
IM MW100-01E
Explanation of Functions
1
Event Action Function
The event action function is used to execute an action such as starting or stopping the
recording by detecting an event such as an alarm occurrence or digital input.
By linking the Event function and Action function, you can control the operations of the
main unit.
Event Types
The following types of events are available. Some items may not be available depending
on the options installed.
Event Type Notation Start Specification
Digital input DI Channel number
Alarm occurrence Alarm
Alarm on specified channel Alarm Channel Channel number, alarm level number
Recording start Memory
Relay action Relay Relay number
Timer event occurrence Timer Timer number
Match time event occurrence Match Time Match time number
User function key User Key Keys number
The following Actions are available. The items that can be set differ according to the
events and event detection method.
Action Notation Detection Method
Edge Level
Recording start* Memory Start
Recording stop* Memory Stop
Save recorded data in divisions Memory Save
Save thinning recording in divisions Memory Save(T)
Computation start MATH Start
Computation stop MATH Stop
Clear computed values MATH Clear
Reset computed values MATH Reset
Reset MATH on specified MATH Reset Gr.1
MATH group number MATH Reset Gr.2
(Gr.1-7) MATH Reset Gr.3
MATH Reset Gr.4
MATH Reset Gr.5
MATH Reset Gr.6
MATH Reset Gr.6
Trigger occurrence on Trigger1
specified number Trigger2
Trigger3
Alarm ACK Alarm ACK
Flag Flag
Reset timer of specified Timer 1 Reset
number (1-6) Timer 2 Reset
Timer 3 Reset
Timer 4 Reset
Timer 5 Reset
Timer 6 Reset
1.3 Functions of the Main Module
