1-33
IM MW100-01E
Explanation of Functions
1
Thermocouple (cont.)
Measurement Range Notation Rated Measurement Range
Type-L L –200.0 to 900.0°C
Type-U U –200.0 to 400.0°C
KPvsAu7Fe KPvsAu7Fe 0.0 to 300.0 K
PLATINEL PLATINEL 0.0 to 1400.0°C
PR40-20 PR40-20 0.0 to 1900.0°C
NiNiMo NiNiMo 0.0 to 1310.0°C
WRe3-25 WRe3-25 0.0 to 2400.0°C
W/WRe26 WWRe26 0.0 to 2400.0°C
Type-N (AWG14) N14 0.0 to 1300.0°C
TXK GOST XK –200.0 to 600.0°C
Resistance Temperature Detector (1 mA)
Measurement Range Notation Rated Measurement Range
Pt100 Pt100-1 –200.0 to 600.0°C
JPt100 JPt100-1 –200.0 to 550.0°C
Pt100 (high resolution) Pt100-1H –140.00 to 150.00°C
JPt100 (high resolution) JPt100-1H –140.00 to 150.00°C
Ni100 SAMA Ni100SAMA –200.0 to 250.0°C
Ni100 DIN Ni100DIN –60.0 to 180.0°C
Ni120 Ni120 –70.0 to 200.0°C
Pt50 Pt50 –200.0 to 550.0°C
Cu10 GE Cu10GE –200.0 to 300.0°C
Cu10 L&N Cu10LN –200.0 to 300.0°C
Cu10 WEED Cu10WEED –200.0 to 300.0°C
Cu10 BAILEY Cu10BAILEY –200.0 to 300.0°C
J263B J263B 0.0 to 300.0 K
Cu10 at 20°C Cu10a392 –200.0 to 300.0°C
alpha=0.00392
Cu10 at 20°C Cu10a393 –200.0 to 300.0°C
alpha=0.00393
Cu25 at 0°C Cu25 –200.0 to 300.0°C
alpha=0.00425
Cu53 at 0°C Cu53 –50.0 to 150.0°C
alpha=0.00426035
Cu100 at 0°C Cu100 –50.0 to 150.0°C
alpha=0.00425
Pt25 (JPt100 × 1/4) Pt25 –200.0 to 550.0°C
Cu10 GE (high resolution) Cu10GEH –200.0 to 300.0°C
Cu10 L&N (high resolution) Cu10LNH –200.0 to 300.0°C
Cu10 WEED (high resolution) Cu10WEEDH –200.0 to 300.0°C
Cu10 BAILEY (high resolution) Cu10BAILEYH –200.0 to 300.0°C
Pt100 GOST Pt100G –200.0 to 600.0°C
Cu100 GOST Cu100G –200.0 to 200.0°C
Cu50 GOST Cu50G –200.0 to 200.0°C
Cu10 GOST Cu10G –200.0 to 200.0°C
1.5 Functions of the 10-CH, Medium-Speed Universal Input Module
