YOKOGAWA MW100 User Manual

1-45
IM MW100-01E
Explanation of Functions
1
Output Operation through Setting Changes (Common)
Setting Changes (Contents) Output Operation
Setting changes for operation Prev. value held → preset value Outputs the preset value the on
startup next time the power is
turned ON
Preset value → hold prev. value The last output value from the
previous operation is held for the
next time the power is turned ON
(outputs the output value active
when the power was last turned
OFF during the previous session)
Setting changes for operation Prev. value held → preset value Outputs the preset value the
upon error occurrence next time
an error occurs
Preset value → hold prev. value Holds the last output value active
before the error occurs for the
next time an error occurs.
Preset value setting changes
*
No changes (as above)
Change setting of output ch from Enabled → Disabled Holds the output value (last
output value)
* Changes are also applied to inactive channels.
Output Operation through Setting Changes (Individually by Output Setting)
Output Setting Setting Changes (Contents) Output Operation
Transmission Range setting AO: V ↔ mA Output value held
output Within changes
PWM: 1 ms ↔10 ms or interval
(until the next output event)
units
Operation Transmission within units →
setting changes arbitrary output
Span setting changes
Arbitrary Range setting AO: V ↔ mA Output value held
output changes
PWM: 1 ms ↔10 ms or interval
(until the next output event)
Operation Arbitrary output →
setting changes transmission within a unit
When the range settings of a PWM output module are changed, the output value is not held.
1.11 Operation of the 8-CH Medium-Speed Analog Output Module and the 8-CH Medium Speed PWM Output Module
