YOKOGAWA MW100 User Manual

4-4
IM MW100-01E
Display Possible Problem Corrective Action
E111 Invalid channel number for alarm event. Set an input module or MATH channel number.
E112 Invalid relay number for relay event. Set the channel number for the DO module.
E113 Invalid action type. Enter a correct action type.
E114 Invalid combination of edge and level detection Set the edge and level detection types to something different.
actions.
E115 Invalid combination of level detection actions. Set events of different types to different actions in level
detection.
E116 Invalid fl ag number. Enter a correct fl ag number.
E120 Invalid measurement group number. Set the measurement interval so that meas. gr 1 ≤ meas. gr 2
≤ meas. gr 3. The maximum allowable ch for 10 ms
measurement is 10, and for 50 ms, 30.
E121 Invalid measurement group number for MATH Set MATH interval to a measurement group of 100 ms or
interval. longer.
E130 Size of data fi le for measurement group 1 Set the number of saved channels, recording interval, and
exceeds the upper limit. recording data length so that the data fi le of measurement
group 1 does not exceed 10 MB.
E131 Size of data fi le for measurement group 2 Set the number of saved channels, recording interval, and
exceeds the upper limit. recording data length so that the data fi le of measurement
group 2 does not exceed 10 MB.
E132 Size of data fi le for measurement group 3 Set the number of saved channels, recording interval, and
exceeds the upper limit. recording data length so that the data fi le of measurement
group 3 does not exceed 10 MB.
E133 Size of MATH data fi le exceeds the upper limit. Set the number of saved channels, recording interval, and
recording data length so that the MATH data fi le does not
exceed 10 MB.
E134 Size of thinned data fi le exceeds the upper limit. Set the number of saved channels, recording interval, and
recording data length so that the thinned data fi le does not
exceed 10 MB.
E135 Cannot set smaller value for thinning recording Set a value for the thinning recording interval higher than
interval than measuring or MATH interval. the measurement and MATH interval.
E136 Invalid combination of thinning recording, Set a value for the thinning recording interval that is a common
measuring and MATH interval. multiple of the measurement and MATH intervals.
E137 Combination of thinning recording interval and Set the thinning recording data length to an integer multiple
thinning recording data length incorrect. of the thinning recording interval.
E138 Cannot set recording operation for measurement Set the measurement interval of the measurement group
group with no measuring interval. number to something other than OFF.
E139 Invalid recording interval. Set a recording interval which can be set to the measurement
interval of the measurement group.
E140 Upper and lower limits of the display zone cannot Set the upper and lower limits of display zone to a different
be equal. value.
E141 Cannot set smaller value than lower limit of Set a larger value for the upper limit than that of the lower limit.
display zone for upper limit.
E142 Width of display zone must be 5% of that of the Set the upper and lower limits so that the difference between
entire display or more. them is 5% or more.
E145 Incorrect display group format. Enter a display group of the correct format.
E150 IP address must belong to class A, B, or C. Set an IP address belonging to class A, B, or C.
E151 Net or host part of IP address is all 0’s or 1’s. Set a valid combination of IP address and subnet mask.
E152 Invalid subnet mask. Enter a setting according to your network.
E153 Invalid gateway address. Make sure that the network part of the IP address and default
gateway match.
E160 Incorrect alarm e-mail channel format. Specify a channel using the correct format.
E165 Invalid channel number for Modbus command. Enter a correct channel.
E166 Invalid combination of start and end channel for Set the fi rst and last channel to the same type.
Modbus command.
4.1 Error Display on the 7-Segment LED and Corrective Actions
