YOKOGAWA MW100 User Manual

5-16
IM MW100-01E
5.2 Main Module Specifications
Communication Input Function
All settings on the main unit other than dip switch operation can be performed with
communication commands. For information about communication commands, see the
MW100 Communication Command manual (IM MW100-17E).
Communication Output Function
The following information about the main unit can be output using communication
commands. For information about communication commands, see the MW100
Communication Command manual (IM MW100-17E).
Item Description
Measured value Outputs most recent measured value
Computed value Outputs most recent computed value
Output value Outputs most recent output value
Units, decimal place Outputs the units and decimal place for measured and
computed values
Measured and computed value Outputs the measured and computed values from the FIFO
FIFO data buffer
Thinned values FIFO data Outputs the thinned values from the FIFO buffer
Alarm summary Outputs the alarm summary
Message summary Outputs the message summary
Recording log Outputs the recording log
Computation status Outputs the MATH status
Recording status Outputs the recording status
Operation log Outputs the key operation log
Communication log Outputs the communication log
FTP log Outputs the FTP operation log
SMTP client log Outputs the mail transmission log
DHCP log Outputs the DHCP log
HTTP log Outputs the HTTP log
Modbus client log Outputs the Modbus client log
Modbus client command Outputs the Modbus client status
Modbus client connection status Outputs the Modbus client connection status
Modbus master log Outputs the Modbus master log
Modbus master command Outputs the Modbus client status
Modbus master connection status Outputs the Modbus master connection status
Status Status byte information
User information User settings
Relay information Relay action information
System information Outputs the module recognition status
Analog output information Outputs the analog output value information
Initial balancing information Outputs initial balance information for the strain input module
Communication Test: This function checks whether the FTP and mail transmission
settings are entered correctly.
Notation Description
FTP1 Transfers a test file to recipient 1.
FTP2 Transfers a test file to recipient 2.
SMTP1 Transfers a test mail to recipient 1.
SMTP2 Transfers a test mail to recipient 2.
