Explanation of Functions
1
• Special math processing on reference channels in TLOG and CLOG
computation*2
Reference channel Notation Processing
status
Abnormal input value Error MATH result error
Skip Continue the computation using the previous value
ignoring the abnormal input value
Overflow value Error MATH result error
Skip Continue the computation using the previous value
ignoring the overflow value
Limit*3 Continue the computation by replacing the overflow value
with upper or lower limit value
*2 If you select Skip or Limit, the maximum, minimum, and maximum-minimum values of the
TLOG and CLOG computation are computed using the overflow value.
*3 The upper or lower limit value that is replaced for the reference channel varies depending on
the MATH type.
Input channel: Upper/lower limit of the measurement range
Scaled input channel: Upper/lower limit of scaling
MATH channel: Upper/lower limit of span
Overflow Processing upon TLOG.PSUM Computation Overflow
You can select an integral value process for when the TLOG.PSUM integral value
overflows from the following items.
Choice for the Computed Result Notation
When 99999999 is exceeded, computation stops as an overflow Over
When 99999999 is exceeded, the next count is 0, and computation continues. Rotate
TLOG.SUM Computation Integration Units
The units of integration are as follows:
IIntegration Units Notation Explanation
No time scale Off Σ (data)*
Every second Sec Σ (data)/(Number of times of computing per second.)
Every minute Min Σ (data)/(Number of times of computing per minute.)
Every hour Hour Σ (data)/(Number of times of computing per hour.)
* Integration of data every MATH integral number of times
1.13 MATH Function (/M1 Option)
