Zebra ZD620 - Page 162

To Next Page

To Previous Page

162

Setup

Note • The maximum roll width of 110 mm (4.3 inches) does not require centering. For

media less than maximum width down to the minimum width of 33mm (1.3 inches), use the

graduated scale on the adapter core to align the ribbon rolls to the media and printer.

Flange - Place on Left

Ribbon Exiting the
