163
Setup
3. Place the adapter with an empty core on the take-up spindles and the adapter with
the ribbon roll on the lower supply spindles. The right side of the core adapter fits on
the cone tip on each of the spring loaded right side spindles. Continue pushing the
adapter onto right side spindle and swing the adapter onto the left side spindle hubs.
Rotate the adapters and hubs until the until notches on the adapters flange align and
lock ton the left spindles hub spokes.
