Chapter 5 Web Interface Tutorials

AX/DX/EX/PX Series User’s Guide

103

4 Go to the Wireless > Guest/More AP screen and click the Modify icon. The following screen appears.

Configure the Security Mode and Password using the provided parameters and click OK.
