Chapter 8 Broadband
AX/DX/EX/PX Series User’s Guide
210
Bridge Mode
Click the Add new WAN Interface in the Network Setting > Broadband screen or the Edit icon next to the
connection you want to configure. The following example screen displays when you select Bridge
mode.
Manually
Configured
Select Manually Configured if you have the IPv6 address of the relay server. Otherwise, select
Automatically configured by DHCPC to have the Zyxel Device detect it automatically through
DHCP.
DS-Lite Relay
Server IP
Specify the transition router’s IPv6 address.
DHCPv6 Option (This is available only when you select IPv6 Only or IPv4 IPv6 DualStack in the IPv4/IPv6 Mode field.)
IPv6 Address
From DHCPv6
Server
Click the switch to let the Zyxel Device send DHCP requests to the DHCPv6 server to obtain an
IPv6 address.
Other
Information
From DHCPv6
Server
Click the switch to have the Zyxel Device get other information, such as DNS information, from
DHCPv6 packets sent from the DHCPv6 server.
This will be enabled if IPv6 Address From DHCPv6 Server is enabled.
IPv6 MAP This is available when you edit an IPv6 WAN interface. Slide the switch to the right to create an
IPv6 map domain.
Transport Mode Select MAP-T (Translation) or MAP-E (Encapsulation) based on the ISP deployment.
Setting Mode Select DHCP S46 or Manual to configure the following fields.
Note: The following Prefix/Address fields are used for the address mapping rule of MAP-T or MAP-E.
BR IPv6 Prefix This is the IPv6 network address/prefix assigned to the BR, including the prefix length.
Rule IPv6 Prefix This is the IPv6 network prefix, including the prefix length.
Rule IPv4 Prefix This is the IPv4 network prefix, including the prefix length.
Note: The following PSID fields are used for the port mapping rule of MAP-T or MAP-E.
PSID Offset The Port Set Identifier (PSID) offset specifies the excluded port range. The default PSID Offset is 6;
port 0~1023 will be reserved for the system to use.
PSID Length This specifies the number of sharing ratio. When PSID Length is set to 8, the ports will be separated
and assigned for 2^8 MAP CEs to use.
PSID A Port Set ID (PSID) identifies a set of ports assigned to a CE for mapping. PSID should be unique
for each CE sharing the IPv4 address.
Cancel Click Cancel to restore your previously saved settings.
Apply Click Apply to save your changes.
Table 45 Network Setting > Broadband > Add or Edit New WAN Interface (Routing Mode) (continued)
LABEL DESCRIPTION
