Static Link Aggregation (LAG) Equipment and Port Configuration
Allocating Ethernet Ports to LAGs
In order to configure LAGs:
ETH ports can be bundled in the same LAG only if they have the same: Mode,
Classification and RED.
STP must be disabled on all ports. All ports except for the first that is added, must have
none VLAN membership.
Therefore: for each port disable STP and except for first port, disable VLANs.
To assign Ethernet ports to a LAG
NOTE: HSL Ethernet ports cannot be assigned to a LAG.
1. Referring to Ethernet Service, HSL and COLAN Ports Configuration, access the Ethernet
Configuration dialog of each port that will be allocated to a LAG and configure the
following parameters:
Under Physical Interface, set Mode to 10FD, 100FD or 1000FD.
Select full-duplex modes only and assign the same speed for all Ethernet port
allocated to a specific LAG.
Select the LAG to which this Ethernet port will be allocated. (Only enabled LAGs
will be displayed).
2. For (traffic or management) VLAN configuration for a LAG:
Configure ONE of the ports of the LAG according to VLANs (on page 8-1).
The VLAN configuration of the rest of the ports to be allocated to a LAG must be
empty.
