Spectral Profiles Modem Profiles Management Model
3. Configure Line Spectrum Profiles according to the following table and click OK to save.
The new profile will be listed in the glance pane. It will also be removed from the list of
available profile AIDs and added to the available profile for use as templates under the
Copy from Profile option.
Table 26: Configuring Line Spectrum Profiles
Choose from the available Profile AIDs.
Assign the profile an identifiable Description (i.e. ADSL2 Plus...)
Do one of the following: either upload values from an existing file and modify them
according to the following step, or define each parameter as described in the next
steps.
Copy values from an
existing profile
Under Copy from Profile (bottom of the pane), choose from the list of predefined
profiles.
Click Get. The parameters will be updated.
Modify the required parameters to customize them to your needs.
Click OK. The new profile will be added to the Line Spectrum Profile pane.
Enable the Allow VDSL2 check box
Select Annex A or Annex B according to your region (Europe or North America).
Select up to three VDSL2 options (priority ranked), each option with its profile (e.g. 8b,
12a, 17a) and the corresponding Mode Specific Profile.
Define ADSL2/Plus
parameters
Enable Allow ADSL2Plus and/or ADSL2 check box
Under Transmission Mode, select ADSL2 or ADSL2Plus. The relevant fields will be
available.
Define allowed annexes (e.g. Annex J, annex M), multiple selection is allowed. In case
of multiple annexes selection the Annexes have predefined priority left to right. For
example, in case of ADSL2Plus: Annex J, then Annex M, Annex A and Annex B.
Downstream PBO Profiles
DPBO is required to minimize the cross-talk to adjacent services in case that the CO unit is
not installed at the exchange (e.g. at outdoor cabinets). DPBO affects the transmission PSD
from CO unit in order to guarantee spectral compatibility. DPBO is supported only in
ADSL2plus and VDSL2 transmission modes. In this profile, the line configuration
parameters must be set to generate a modified downstream PSD mask for Downstream Power
Back-off.
To generate a DPBO Profile
1. In the Network Element tree, under Modem Profiles and under Spectral Profiles,
select Downstream PBO. The defined profiles are listed in the pane according to their
user assigned description and characteristics.
NOTE: Use the Add/View/Delete Profile buttons to define and manage the profiles.
2. In the displayed pane, click Add Profile. The Downstream PBO profile definition dialog
appears.
