Control of Alarmed Conditions Monitoring
Alarms Pane View
The Alarms pane displays the currently active alarms and the Alarms History tables for
Network Element currently selected in the tree. The Alarms pane at the bottom provides a
summary of the current alarms from all NEs displayed in the tree.
For more information on the alarms, see Alarm Information in Summary Tables (on page
13-7). The Alarms pane also provides access to the Environmental Alarms configuration
options for that NE.
To view the Alarms pane:
On the Navigation tree in the Network Element tree, open System Administration, Alarms.
The Alarms pane opens.
The pane is divided into three areas:
Current alarms - shows active alarms for the NE selected in the Navigation tree
Configure CO Env. Alarms and Alarms Cut Off button - provides access to environmental
alarms configuration options for the NE and Alarms Cut Off option
Alarm History - shows all alarms generated for the selected NE, including those that are
no longer active. (The display is limited to the last 512 alarms).
NOTE: To reset the Alarm History (Admin privileges only), click the Clear History button in the
Alarm History area.
