Alarms and Indications Control
 ML system supports general purpose output (GPO) and general purpose input (GPI)
alarms.
 The GPO can be used to provide ML alarm notification. This option is configured by
default (Office Alarms option) through Output Relays.
 The GPO can also be used to provide external controls such as air-conditioner activation,
via ML systems. The option is configured through Output Relays.
 ML system provides General Purpose Inputs (GPI) that can be used to report external
equipment alarms such as open door or water flood in outdoor cabinet. This option is
implemented through the Environmental Alarms configuration.
General Purpose Output (GPO) Configuration
The Alarm Terminal Block located on the unit rear panel (for details, see unit Rear Panel
Description) supports a General Purpose Output (GPO) in addition to the two environmental
alarm inputs.
The ML device allows you to configure the operational mode of the General Purpose Outputs
(GPO) relay contacts as office alarms or external controls.
The GPO relay contact can be set to one of the following:
 Office alarm indications (Critical/Major)
 External control such as sprinkler, lights, air-conditioning etc.
The default setting is office alarm, which can be connected to external alarm device(s).
Office Alarm Control
A single Normally Open (NO) GPO relay is provided in the ML system for Office Alarm
indication. A sound emitting device can be connected to the Office Alarm relay to provide
audible alarm functionality.
When the unit is configured for Office Alarms and connected to an external audible device
then a Major or Critical alarm raised on the ML device will also activate the Audible office
alarm.
Office Alarm will Close due to:
 Unit initialization
 Critical or Major failure
NOTE: Alarms suppressed due to Partial alarm LED configuration are not reported via GPO.
