High Speed Link (HSL) Equipment and Port Configuration
ML700 User Manual 4-17
High Speed Link (HSL)
ML HSL is a logical port consisting of bonded, multiple MLPs that are allocated to that HSL.
The HSL links an ML700 CO and an ML CPE unit. The HSL is then calibrated according to
predefined calibration profile templates (on page 6-1).
 HSL activation flow is as follows:
 Configure the HSL
 Delete unused MLPs
 Calibrate the HSL - according to predefined profile templates (on page 6-1) (modify the
templates if required)
 Configure Ethernet attributes on the HSL
HSL Workspace
Several views are available for HSL configuration, monitoring and analysis. Each view has a
dedicated set of monitoring and configuration buttons, where some of the options are
common to the different views (the left pane in each view shows how the view is accessed):
 HSL Glance View - summarizes the HSL attributes in tabular format. In addition, the
following buttons are available:
 Configure - HSL configuration dialog
 Configure Alarms (on page 13-10) - alarm configuration for the selected HSL
