Ethernet Service Configuration VLAN and EVC Mapping
10-6 User Manual ML700
VLAN and EVC Mapping
Traffic VLANs can be associated with predefined EVCs when the VLAN is defined or any
time afterwards using the Edit option in the VLAN configuration pane.
NOTE: The following steps refer only to VLAN association to EVC. For a full description of the
VLAN configuration procedure, refer to Traffic VLAN Configuration.
 To associate a VLAN with an EVC
1. In the Network Element tree, expand Ethernet Bridge and select VLANs. The VLANs
pane opens in the work area.
2. Invoke the configuration pane for the required VLAN using one of the following
methods:
 To add an existing VLAN to an EVC, select the VLAN row and click Edit VLAN.
 To add a new VLAN to an EVC, click Add VLAN.
3. In the invoked Traffic VLAN pane, define the necessary parameters and select the EVC
with which the VLAN will be associated.
