Calculating the Range Covered by a Rule
Adding a mask to an explicit number of any field (COS, VID, TOS, etc.) selection, you can
create a rule which covers a RANGE of values.
This section describes how to calculate the range covered by a rule.
NOTE: You may calculate the range using the Range Calculator Dialog (on page 10-23).
Note that:
 Mask bit, when set to 0 – allows both 0 and 1 bits in result,
 Mask bit, when set to 1 – requires result bit to be matched with a field value bit.
COS
Note that COS bit is provided in Decimal format and Mask is in Binary format.
The table below provides an example, how to use/convert formats for COS field
Table 43: COS
Numbering
System
Field Value
Mask
Result
DEC
4
7
{4-5}
HEX
0x4
0x7
{0x4 - 0x5}
BINARY
100
110
100 - 101
VID
Note that VID is provided in Decimal format and Mask is in HEX format.
The table below provides an example, how to use/convert formats for VID field
Table 44: VID
Numbering
System
Field Value
Mask
Result
DEC
16
16
{16-31}
HEX
0x10
0x10
-{0x10 - 0x1F}
BINARY
10000
10000
10000 - 11111
