Ethernet Service Configuration Identification Rules Definition
10-22 User Manual ML700
TOS/DSCP
Note that both TOS/DSCP and Mask fields are provided in HEX format.
Note that TOS/DSCP field values by DSCP standard are provided in Decimal value (0-63),
using 6 bits of 8 bits in a byte (starting from the highest bits of byte). To set TOS/DSCP field
value using HEX format, the value (e.g. PHB (per-hop-behavior) CS6 (class selector 6),
covers DSCP= 48-55) should be translated to BINARY “110000” and extended with “00”
(for 2 lowest bits of the byte), the result value (11000000) should be translated to HEX
format (0XC0) and typed as a field value.
Table 45: TOS
Numbering
System
Field Value
Mask
Result
DEC
192 :
PHB = 48
(x 4) –
shifted left to
2 bits = 192
224
{48 - 55}
HEX
0xC0
0xE0
-{0xC0 - 0xDF}
BINARY
11000000
11100000
11000000 - 11011111
IP Address
Note that both IP Address field and mask are in Dot Numeric (decimal) format
Table 46: IP
Numbering
System
Field Value
Mask
Result
DEC
10.2.17.1
255.255.255.1
10.2.17.{0-255}
BINARY
00001010.
00000010.
00010001.
00000000
11111111.
11111111.
11111111.
00000000
00001010.
00000010.
00010001.
{00000000 – 11111111}
MAC
Note that both MAC address field and mask field are in HEX format.
Table 47: MAC
Numbering
System
Field Value
Mask
Result
HEX
0x00-03-85-
01-01-01
FF-FF-FF-00-00-
00
00-03-85-{00-FF}-{00-FF}-
{00-FF}
BINARY
00001010.
00000010.
00010001.
00000000
11111111.
11111111.
11111111.
00000000
00001010.
00000010.
00010001.
{00000000 – 11111111}
