Appendix E - Factory Setup Content
ML700 User Manual E-5
Rules and Services
Table 102: Services and Rules Factory Setup
Ethernet Services (BW limiting and CLASS of Service)
EVCs
not entered
EVC Services
SERV-1:
EVC AID= “”, DESCR = “INTERNAL HIGH”, BWPROFILEID = 0,
QUEUE=HHH
SERV-2:
EVC AID= “”, DESCR = “INTERNAL LOW”, BWPROFILEID = 0, QUEUE=LLL
SERV-3:
EVC AID= “”, DESCR = “DEFAULT MGMT”, BWPROFILEID = 0,
QUEUE=HHH
SERV-4:
EVC AID= “”, DESCR = “HIGHEST SERVICE UNLIMITED QUEUE”,
BWPROFILEID = 0, QUEUE=H //scheduled as WFQ with weight=8
SERV-5:
EVC AID= “”, DESCR = “HIGH SERVICE UNLIMITED QUEUE”,
BWPROFILEID = 0,
QUEUE=MH //scheduled as WFQ with weight=4
SERV-6:
EVC AID= “”, DESCR = “MEDIUM SERVICE UNLIMITED QUEUE”,
BWPROFILEID = 0, QUEUE=L//scheduled as WFQ with weight=2
SERV-7:
EVC AID= “”, DESCR = “LOW SERVICE UNLIMITED QUEUE”, BWPROFILEID
= 0, QUEUE=LLL//scheduled as WFQ with weight=1
Identification Rules
RULE-1: not editable
Default Template, All Values, except MACDST, =ANY, MACDST = 01-80-C2-
00-00-00, MASKMACDST=FF-FF-FF-FF-FF-F0, PASSTOMETER=Y, SERV-1,
MARKING=NONE, DESCR = L2CP MAC=0x0180C200000*
RULE-2: not editable
Default Template, All Values, except MACDST, =ANY, MACDST = 01-80-C2-
00-00-10, PASSTOMETER=Y, SERV-1, ORDERNUM=-1, MARKING=NONE,
DESCR= " L2CP MAC=0x0180C2000010".
RULE-3: not editable
Default Template, All Values, except MACDST, =ANY, MACDST = 01-80-C2-
00-20,MASKMACDST=FF-FF-FF-FF-FF-FE, PASSTOMETER=Y, SERV-1,
MARKING=NONE, DESCR= "L2CP MAC=0x0180C20020/1".
RULE-4: not editable
Default Template, All Values, except MACDST, =ANY, MACDST =01-00-0c-
00-00-00, MASKMACDST=FF-FF-FF-FF-FF-FF, PASSTOMETER=Y, SERV-1,
MARKING=NONE, DESCR="ISL MAC=0x01000C000000”.
RULE-5: not editable
Default Template, All Values, except MACDST, =ANY, MACDST =01-00-0c-
cc-cc-cc/D, MASKMACDST=FF-FF-FF-FF-FF-FE, PASSTOMETER=Y, SERV-1,
MARKING=NONE, DESCR= "CDP/PVST+ MAC=0x01000 CC-CC-CC-C/Dl”.
RULE-6: not editable
Default Template, All Values, except MACDST, =ANY, MACDST = 01-80-C2-
00-00-30, MASKMACDST=FF-FF-FF-FF-FF-F0, PASSTOMETER=Y, SERV-1,
MARKING=NONE, DESCR= "CFM MAC=0x0180C200003*".
RULE-7:
Default Template, All Values, except VID, =ANY, EXTTAGVID = 100
(MGMTVID), PASSTOMETER=Y,SERV-3, MARKING=NONE, DESCR= "MGMT
VLAN".
