Actelis Networks ML700 - Page 141

STP/RSTP and Provider Bridge Configuration Ethernet Bridge, STP/RSTP
ML700 User Manual 5-27
FIELD
Description
Actual Root
Path Cost
This is the cost for a packet to travel to the root in the current Spanning Tree
configuration. The slower the media, the higher the cost. This is 0 if your bridge is the
root device.
Actual Max Age
This is the maximum time (in seconds) a device can wait without receiving a
configuration message before attempting to reconfigure. Value derived from the Root
port.
Actual Hello
Time
This is the time interval (in seconds) at which the root device (for STP) or any devices
(for RSTP) transmit a configuration message. Value derived from the Root port.
Actual Forward
Delay
This is the time (in seconds) a device will wait before changing states. Value derived
from the Root port.
