Introduction ML700 Front and Rear Panel Descriptions
Table 4: Rear Panel Interfaces
Ports for connection of copper pair wires.
2, 4 or 8 ports (model dependent).
Reset button. Restarts software with current or factory setup
depending on the time duration which it is pressed:
Pressed for up to 10 seconds - restarts with current
configuration.
Pressed for more than 10 seconds - restarts with factory setup.
IN1/IN2 - Two Normally Open (NO) inputs.
OUT - one Normally Open (NO) relay output.
DC Barrier Terminal Block for DC power input.
Power requirement: -48 VDC nominal (-40 to -60 VDC max), 2
Amperes maximum (17W maximum for ML740).
Grounding option for a floating AC/DC converter, refer to ML700
Quick Installation Guide document for details.
